Details about  DSO5102B Digital Storage Oscilloscope 100MHz color UKG

DSO5102B Digital Storage Oscilloscope 100MHz color UKG See original listing
DSO5102B-Digital-Storage-Oscilloscope-100MHz-color-UKG
Item Ended
Item condition:
New
Ended:
22 Jan, 2013 06:54:27 GMT
Price:
£284.99
[
History:
]
Postage:
£58.00 Standard Delivery from outside UK | See details
International items may be subject to customs processing and additional charges.  help icon for delivery - opens a layer
Item location:
CN,CN, China

Description

eBay item number:
290585026178
Seller assumes all responsibility for this listing.
Last updated on  19 Mar, 2012 11:19:57 GMT  View all revisions
IAB AUH
116
EVA notliF
lotsirB
novA
HQ0 7SB
modgniK detinU

:enohP6819032|7110
:liamEmoc.liamtoh@ecnerual_nas

Item specifics

Condition:
New: A brand-new, unused, unopened and undamaged item in original retail packaging (where packaging is ... Read moreabout the condition
Brand:

Hantek

ACCUNI-EXPRESS

Visit my eBay Shop
By placing your bid, you are agree to follow our store policy below: ●All purchased are final, will replace defective product only. ●Return package must be in the original packaging, everything must be in new condition.Missing part’s or anything in original contact will not qualify for any refund. ●Unless marked in the auction, all product follow our 2 months warranty policy. ●Defective item can be exchanged within 7 days of receipt.Please send us some photoes as evidence. ●Within warranty period, all exchanges due to defects are free (Buyer is responsible for shipping charges). ●Shipping and handling fees are NOT refundable in any case. ●Custom duty is responsible by buyer. ●Replacement and refunds will not be processed until the return item received. ●Customer is responsible for correct address and received of package. Customer is responsible to all shipping if return package due to customer unable to received the package. ●Please do not ask us to reduce the price and shipping and handling fee of the item after you have won the auction. ●We are not responsible for wrong or undeliverable address, customer responsible undeliverable Express package return fee and re shipping fee.A valid phone number can make the delivery process more quickly and more safely.



DSO5102B 2Channels Digital Storeage Oscilloscope New



 Feature


• 100MHz bandwidths
• 1GSa/s Real Time sample rate
• Large (7.0-inch) color display,WVGA(800x480)
• Record length up to 1M
• Trigger mode: edge/pulse width/line selectable video/slop/overtime etc.
• USB host and device connectivity, standard
• Multiple automatic measurements
• Four math functions, including FFTs standard
• Provides software for PC real-time analysis

Operating system: Windows NT, Windows 2000, Windows XP ,VISTA,support second Design DEMO code (VC、VB、LABVIEW).

Photobucket


Photobucket


Photobucket


Photobucket

Specification

Model

DSO5202B

DSO5102B

DSO5062B

Bandwidth

200MHz

100MHz

60MHz

Real-time Sample Rate

1GSa/s

Equivalent Sample Rate

25GSa/s

Record Length(Sample Points)

Single-channel: Maximum 1M; Dual-channel:Maximum 512K (4K,16K,40K optional)

SEC/DIV Range

4nS/div-40S/div (in a 2, 4, 8 sequence)

Delay Time Accuracy

500ps

Vertical

A/D Converter

8-bit resolution, each channel sampled simultaneously

VOLTS/DIV Range

2mV/div5V/div at input BNC

Position Range

±50V(5V/div),±40V(2V/div500mV/div),2V(200mV/div50mV/div)±400mV(20mV/div2mV/div)

Rise Time at BNC

≤1.7ns

≤3.5ns

≤5.8ns

DC Gain Accuracy

±4% for Sample or Average acquisition mode, 5mV/div to 2mV/div
±3% for Sample or Average acquisition mode, 5V/div to 10mV/div

Trigger

Trigger Sensitivity
(Edge Trigger Type)

DC: CH1/CH2(Typical) 1div from DC to 10MHz;1.5div from 10MHz to Full
EXT
Typical 200mV from DC to 40MHz
EXT/5
Typical 1V from DC to 40MHz
AC: Attenuates signals below 10Hz

HF Reject: Attenuates signals above 80kHz

LF Reject: Attenuates signals below 150kHz

Noise Reject: Reduces trigger sensitivity

Trigger Level Range

CH1,CH2: ±8 divisions from center of screen
EXT: ±1.2V EXT/5: ±6V

Trigger Level Accuracy,
typical (Accuracy is for signals having rise and fall times ≥20ns)

CH1,CH2: ±(0.3div×V/div) (within ±4 divisions from center of screen)
EXT: ±(6% of setting + 40mV)
EXT/5: ±(6% of setting + 200mV)

Holdoff Range

100ns-10s

Trigger Type

Edge

Trigger on the rising or falling edge

Pulse Width

Trigger (when >,<,=,≠) on positive or negative pulses
Pulse Width Range: 20ns-10s

Video

Trigger on an NTSC, PAL, or SECAM standard video signal
Line Range: 1-525 (NTSC), 1-625 (PAL/SECAM)

Slope

Trigger (when >,<,=,≠) on a positive or negative slope
Set Time: 20ns–10s

Overtime

from the rising or falling edge
Set Time: 20-10s

Alternate

Internal trigger on edge, pulse width, video or slope

Measurement

Cursors

Manual: The difference between voltage cursors V; the difference between time cursors T; 1/T calculated by Hz.
Tracing: The voltage and time at a waveform point

Automatic

Pk-Pk, Max, Min, Mean, Cyc RMS, Frequency, Period, Rise Time, Fall Time, Positive Width, Negative Width

Display

Type

Right angle 7"TFT 16-digit color LCD

Resolution

800*480 dots

Contrast

16 gears, with the progress bar to show adjustment

Interface

USB host and USB slave

Power Supply

Voltage

100-120VACRMS(±10%)45Hz to 440HzCAT
120-240VACRMS(±10%)
45Hz to 66HzCAT

Power

<30W

Fuse

2A, T rating, 250V

Mechanical

Size

Length: 313mm Width: 108mm Height: 142mm

Net Weight

2.08KG (exclusive of packing and accessories)

If need other 2models,please contact us!

 It has these standard parts:
















The Signal test and display as shown
